Enhanced Weight & Balance
Easily create and edit Weight & Balance profiles with enhanced interface, standard weights, and saved loads.
Individual customers now have access to our Enhanced Weight & Balance to simplify your preflight workflow. Currently, the new paradigm is optional so you can migrate your aircraft profiles when it is most convenient for you and still revert to the old paradigm if you want. However, the new paradigm will fully replace the old one later this year.
Start by going to More > Account > ForeFlight Labs and tapping the Enhanced Weight & Balance toggle to enable it. If you need to go back to the old Weight & Balance view at any time, just disable this setting.
To start migrating your existing W&B profiles, go to More > Weight & Balance and use the drop-down in the top left to select a profile. ForeFlight’s Migration Assistant will then walk you through a 4-step process to set them up with the new system.
Enhanced W&B profiles are tied directly to the aircraft profiles you use for flight planning to create a more robust and unified aircraft profile, so start by choosing an aircraft to associate with the Weight & Balance profile. Connecting the two will ensure that your current aircraft details are merged with your new W&B profile.
If your aircraft details differ from your Weight & Balance profiles, you will need to select the correct one to move to the next step.
The third step is to verify station details. Tap on any station to view and edit its name, arm length, and station type.
The final step in the migration process is to verify the number of seats per station. The Migration Assistant assumes two seats per station by default, so it’s especially important to review and correct any discrepancies for rows with a different number of seats. Tap Done to complete the profile migration.
You can always edit these numbers in the future by tapping Edit next to the Profile Selector in the new W&B view.
You can also add new Weight & Balance profiles if you don’t have any to migrate. ForeFlight provides hundreds of pre-built templates to choose from, and they are easy to add to an existing Aircraft. Go to More > Aircraft, select the aircraft you want to edit, and tap Weight & Balance Profile halfway down the page. If a template is available for your aircraft type it will be listed at the top, or you can select Blank Template to create your own.
Next, add or edit the profile’s name, specify your aircraft’s basic empty CG and weight, verify or add station details and forward and aft CG limits, and enable the %MAC setting at the bottom of the page if applicable to your aircraft. ForeFlight has five station types to choose from and edit: Single Seat, Row of Seats, Cargo, Fuel, and Aircraft Items.
Once you’ve migrated or set up your Enhanced Weight & Balance profiles, you can use the new W&B view in the same way as before. The new W&B is very similar to the previous paradigm but allows for more flexibility when inputting calculations for each seat and station.
Manually input the weight for each seat with an optional description or choose from Standard Weights or Saved Loads. Standard Weights default to Male: 205 lbs, Female: 184lbs, and Child: 87 lbs; however, you can change those values by visiting More > Settings > Standard Weights (at the very bottom of the page). Saved Weights include any weights you added manually with a description or loads migrated from your legacy profiles.
You will need to adjust fuel and cargo and can do so by scrolling down a little further.
